The following accessories should be included inside the box with your unit:
- External AC power supply
- AC mains
- Stick for under-panel dipswitches settings
- Warranty and product registration information (USA and Canada only)
110LP v2 Phono Preamplifier
Sound Quality
Developed with award-winning technologies used in our more exotic phono preamplifiers, the MOON 110LP v2 represents another leap forward in sound quality and affordability.
Dynamic
Enjoy all of the MOON sonic characteristics available at a lower cost than ever; fast, tight, extended bass response, a natural open midrange, and airy extended high frequencies. This is achieved through the combination of an improved power supply and an enhanced circuit layout. Another benefit is an increased input overload margin for trouble free use.
Convenient & Flexible
In a matter of just a few seconds, you can easily configure under the unit each of these four parameters: gain, curve, resistance and capacitance. As a result, replacing your cartridge will not render the MOON 110LP v2 obsolete.
No compromise
“This is one fabulous piece of equipment. No other entry-level phono preamp I’ve heard betters its design, its construction, or, most important, its sound.”
– Thom Moon, SoundStage! Network
Phono PreamplifiersSpecifications
Product features
In the box
User manual
Comparison chart
Design features
End-user adjustable impedance loading (47kΩ, 475Ω, 100Ω, 10Ω)
End-user adjustable capacitance loading (0pF, 100pF, 330pF, 430pF)
End-user adjustable gain settings for moving magnet and moving coil cartridges (40dB, 50dB, 54dB, 60dB, 66dB)
End user selectable curve (IEC/RIAA)
Four layer PCB tracings using pure copper for low impedance characteristics
Inductive DC Filtering for a significantly lower noise floor
Compact, rigid all-aluminum chassis with gold-plated RCA connectors
Designed to be powered up at all times for optimal performance
Specifications
- Circuit LayoutMirror-image symmetrical circuit
- Single-ended inputs1 pair (RCA)
- Input Impedance - Adjustable10Ω / 100Ω / 475Ω / 47kΩ
- Input Capacitance - Adjustable0 / 100pF / 330pF / 430pF
- Gain Level - Adjustable40dB / 50dB / 54dB / 60dB / 66dB
- CurveIEC / RIAA
- Signal-to-noise Ratio (full scale @40 dB gain)104 dB
- Signal-to-noise Ratio (full scale @60 dB gain)87 dB
- Frequency Response20Hz - 20kHz (± 0.5dB)
- Intermodulation Distortion0.002%
- THD (20Hz - 20kHz)0.002%
- Power Consumption @ idle2 W
- AC Power Requirements100-240V 50Hz / 60 Hz
- Shipping Weight3.3 lb / 1.5 kg
- Dimensions (W x H x D)5.0 x 1.65 x 6.5 in
- 12.7 x 4.2 x 16.5 cm
Level Up
Do you want an even higher level of performance in this product category? Take a look at this:
-
310LP
Phono PreamplifierThe finest mid-priced phono preamplifier just got even better. The MOON 310LP Phono Preamplifier elevates the performance of its highly acclaimed predecessor to another level.
